1.6A 2.5A Overload Relay D Range

Price - Rs. 9,760.00

WEDABIMA HARDWARE Electrical Products

0774953653

info@wedabimahardware.lk

Sausiri Complex , High Level Road , Nugegoda

Description

Brand - Schneider

Model - LRD07

Range - TeSys

Product Name - TeSys LRD
TeSys Deca

Product or Component Type - Differential thermal overload relay

Device short Name - LRD

Relay Application - Motor protection

Product Compatibility - LC1D18
LC1D38
LC1D32
LC1D25
LC1D12
LC1D09

Network Type - DC/AC

Thermal overload class - Class 10A conforming to IEC 60947-4-1
Thermal protection adjustment range - 1…2.5 A

[Ui] rated insulation voltage - Power circuit: 600 V conforming to CSA
Power circuit: 600 V conforming to UL
Power circuit: 690 V conforming to IEC 60947-4-1

Complementary
Network frequency - 0...400 Hz
Mounting support - Plate, with specific accessories
Rail, with specific accessories
Under contactor

Tripping threshold - 1.14 +/- 0.06 Ir conforming to IEC 60947-4-1
Auxiliary contact composition - 1 NO + 1 NC
[Ith] conventional free air thermal current - 5 A for signalling circuit

Permissible current - 3 A at 120 V AC-15 for signalling circuit
0.22 A at 125 V DC-13 for signalling circuit
[Ue] rated operational voltage - 690 V AC 0...400 Hz for power circuit conforming to IEC 60947-4-1

Associated fuse rating - 4 A gG for signalling circuit
4 A BS for signalling circuit
[Uimp] rated impulse withstand voltage - 6 kV

Phase failure sensitivity - Tripping current 130 % of Ir on two phase, the last one at 0
Control type - Red push-button: stop
Blue push-button: reset

Temperature compensation - 20…60 °C
Connections - terminals Control circuit: screw clamp terminals 2 cable(s)

1…2.5 mm² flexible without cable end
Control circuit: screw clamp terminals 2 cable(s) 1…2.5 mm² flexible with cable end
Control circuit: screw clamp terminals 2 cable(s) 1…2.5 mm² solid without cable end
Power circuit: screw clamp terminals 1 cable(s) 1.5…10 mm² flexible without cable end
Power circuit: screw clamp terminals 1 cable(s) 1…4 mm² flexible with cable end
Power circuit: screw clamp terminals 1 cable(s) 1…6 mm² solid without cable end

Tightening torque - Control circuit: 1.7 N.m - on screw clamp terminals
Power circuit: 1.7 N.m - on screw clamp terminals
Height - 66 mm
Width - 45 mm
Depth - 70 mm
net weight - 0.124 kg

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 8.800 cm
Package 1 Width - 7.700 cm
Package 1 Length - 4.900 cm
Package 1 Weight - 138.000 g
Unit Type of Package 2 - S02

Number of Units in Package 2 - 24
Package 2 Height - 15.000 cm
Package 2 Width - 30.000 cm
Package 2 Length - 40.000 cm
Package 2 Weight - 3.653 kg

Unit Type of Package 3 - P06
Number of Units in Package 3 - 384
Package 3 Height - 75.000 cm
Package 3 Width - 60.000 cm
Package 3 Length - 80.000 cm
Package 3 Weight - 72.827 kg

18 Months Company Warranty

wedabima.com and D Factor Group make no warranty or representation for any products, services, deals and transactions between the user and the advertisers. Users strictly at their own risk.

Related Items

3 Pole - 32A Schneider Miniature Circuit Breaker

Rs. 8,130.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

3 Pole - 32A Schneider Miniature Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - A9N3P32C Device application - Distribution Range of, etc... Find best deals from වැඩබිම

0774953653

4 Pole 63A 100MA Residual Current Circuit Breaker

Rs. 22,540.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

4 Pole 63A 100MA Residual Current Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - EZ9R56463 Range of Product - Easy9 Product or Component, etc... Find best deals from වැඩබිම

0774953653

1 Pole - 16A Schneider Miniature Circuit Breaker

Rs. 1,750.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

1 Pole - 16A Schneider Miniature Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - A9N1P10C Range of Product - Distribution Product or Comp, etc... Find best deals from වැඩබිම

0774953653

4 Pole - 25A Schneider Miniature Circuit Breaker

Rs. 13,140.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

4 Pole - 25A Schneider Miniature Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - A9N4P25C Device application - Distribution Range of, etc... Find best deals from වැඩබිම

0774953653

100A 3P - 15KA Schneider Circuit Breaker

Rs. 23,040.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

100A 3P - 15KA Schneider Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - EZC100N3100 Range of Product - EasyPact Product or Component Ty, etc... Find best deals from වැඩබිම

0774953653

2.5A - 4A Overload Relay - D Range
