Home Electrical Switch Sockets WEDABIMA HARDWARE Electrical Products 600A 3P 36KA Schneider Circuit Breaker
Price - Rs. 247,430.00
info@wedabimahardware.lk
Sausiri Complex , High Level Road , Nugegoda
Brand - Schneider
Model - LV563306
Range of Product - EasyPact CVS400...630
Product Name - EasyPact CVS
Device short name - CVS630F
Product or Component Type - Circuit Breaker
Device Application - Distribution
Poles Description - 3P
Protected Poles Description - 3D
Earth leakage protection (Vigi add on) Without
[In] Rated current 600A at 40 °C
Network Type - AC
Utilisation Category - Category A
[Icu] Breaking capacity - 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
36 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
30 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
Trip unit name - TM-D
Trip unit technology - Thermal-magnetic
Trip unit rating - 600A at 40 °C
Protection type - Short-circuit protection (magnetic)
Overload protection (thermal)
Complementary
[Uimp] rated impulse withstand voltage - 8 kV conforming to EN/IEC 60947-2
Network frequency - 50/60 Hz
Breaking capacity code - F
[Ics] rated service breaking capacity - 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
36 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
23 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
Mechanical durability - 15000 cycles
Electrical durability - 4000cycles 415 V In conforming to IEC 60947-2
Control type - Toggle
Thermal protection adjustment range - 420..…600A
Long time pick-up adjustment type Ir - Adjustable
Long time pick-up adjustment range - 0.7...1 x In
Long time delay adjustment type - Fixed
Instantaneous pick-up adjustment type Ii - Adjustable
Instantaneous pick-up adjustment range - 4...8 x In
Contact position indicator - Yes
mounting support - Backplate
mounting mode - Fixed
Upside connection - Front
downside connection - Front
Connections - terminals - Screw connection
Connection pitch - 45 mm
Compatibility code - CVS630
Width - 140 mm
Depth - 110 mm
Height - 255 mm
net weight - 5.2 kg
Environment
Standards - IEC 60947-2 /EN 60947-2
product certifications - GOST IEC
Electrical shock protection class - Class II
Pollution degree - 3 conforming to IEC 60664-1
IP degree of protection - IP40
ambient air temperature for operation -25…70 °C
ambient air temperature for storage -50…85 °C
Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 15.000 cm
Package 1 Width - 15.500 cm
Package 1 Length - 28.700 cm
Package 1 Weight - 5.318kg
Unit Type of Package 2 - S04
Number of Units in Package 2 - 3
Package 2 Height - 30.000 cm
Package 2 Width - 40.000 cm
Package 2 Length - 60.000 cm
Package 2 Weight - 16.604 kg
