Home Electrical Switches & Socket Outlets WEDABIMA HARDWARE Electrical Products 2 Pole 16A Schneider Miniature Circuit Breaker
Price - Rs. 4,500.00
info@wedabimahardware.lk
Sausiri Complex , High Level Road , Nugegoda
Brand - Schneider
Model - A9N2P16C
Range of Product - Distribution
Product or Component Type - Acti9
Range - Acti9
Product name - XC60
Product or Component Type - Miniature circuit-breaker
Device short Name - XC60
Poles Description - 2P
Number of Protected Poles - 2
[In] Rated Current - 16 A
Network Type - DC/AC
Trip Unit Technology - Thermal-magnetic
Curve Code - C
Utilisation Category - Category A conforming to EN/IEC 60947-2
Suitability for Isolation - Yes conforming to EN/IEC 60947-2
Complementary
Network frequency - 50/60 Hz
[Ue] rated operational voltage - 240 V AC 50/60 Hz
380...415 V AC 50/60 Hz
100...125 V DC
Magnetic tripping limit - 8 x In +/- 20 %
Breaking capacity - 10000 A Icn at 240 V AC 50/60 Hz conforming to EN/IEC 60898-1
10000 A Icn at 415 V AC 50/60 Hz conforming to EN/IEC 60898-1
10 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-2
6 kA Icu at 100...125 V DC conforming to EN/IEC 60947-2
[Ics] rated service breaking capacity - 6 kA conforming to EN/IEC 60947-2 - 100...125 V DC
7.5 kA conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz
Limitation class - 3 conforming to EN/IEC 60898-1
3 conforming to EN/IEC 60947-2
[Ui] rated insulation voltage - 500 V AC 50/60 Hz conforming to EN/IEC 60947-2
[Uimp] rated impulse withstand voltage - 6 KV conforming to EN/IEC 60947-2
Contact position indicator - Yes
Control type - Toggle
Local signalling - ON/OFF indication
mounting mode - Clip-on
mounting support - 35 mm DIN rail
Comb busbar and distribution block compatibility - Top: YES
9 mm pitches - 4
Height - 85 mm
Width - 36 mm
Depth - 77.5 mm
net weight - 0.215 kg
Colour - White
Mechanical durability - 20000 cycles
Electrical durability - 20000 cycles
Connections terminals - Tunnel type terminals (bottom) 16 mm² flexible
Tunnel type terminals (bottom) 25 mm² rigid
Biconnect (top)
Wire stripping length - 13 mm for top or bottom connection
Tightening torque - 2 N.m
Earth-leakage protection - Separate block
Product compatibility - C60 auxiliary
C60 accessories
Overvoltage category - IV
Environment
Standards EN/IEC 60898-1
EN/IEC 60947-2
Pollution degree - 3
Tropicalisation - 2 conforming to IEC 60068-1
Relative humidity - 95 % at 55 °C
ambient air temperature for operation - 30…70 °C
ambient air temperature for storage - 40…85 °C
Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 5 cm
Package 1 Width - 9.2 cm
Package 1 Length - 8.4 cm
Package 1 Weight - 220 g
Unit Type of Package 2 - BB1
Number of Units in Package 2 - 6
Package 2 Height - 8.8 cm
Package 2 Width - 9.6 cm
Package 2 Length - 24.2 cm
Package 2 Weight - 1.34 kg
Unit Type of Package 3 - CAR
Number of Units in Package 3 - 72
Package 3 Height - 27.8 cm
Package 3 Width - 30.2 cm
Package 3 Length - 35.6 cm
Package 3 Weight - 16.7kg
