100A 3P 25KA Schneider Circuit Breaker

Price - Rs. 37,940.00

WEDABIMA HARDWARE Electrical Products

0774953653

info@wedabimahardware.lk

Sausiri Complex , High Level Road , Nugegoda

Description

Brand - Schneider

Model - LV510307

Range of Product - EasyPact CVS100...250

Product Name - EasyPact CVS

Device short name - CVS100B

Product or Component Type - Circuit Breaker

Device Application - Distribution

Poles Description - 3P

Protected Poles Description - 3D

Earth leakage protection (Vigi add on) Without

[In] Rated current 100A at 40 °C

Network Type - AC

Utilisation Category - Category A

[Icu] Breaking capacity - 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2

Trip unit name - TM-D
Trip unit technology - Thermal-magnetic
Trip unit rating - 100A at 40 °C
Protection type - Short-circuit protection (magnetic)
Overload protection (thermal)

Complementary
[Uimp] rated impulse withstand voltage - 8 kV conforming to EN/IEC 60947-2
Network frequency - 50/60 Hz
Breaking capacity code - B
[Ics] rated service breaking capacity - 15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2

Mechanical durability - 30000 cycles
Electrical durability - 12000 cycles 415 V In conforming to IEC 60947-2
Control type - Toggle
Thermal protection adjustment range - 70..…100 A
Long time pick-up adjustment type Ir - Adjustable

Long time pick-up adjustment range - 0.7...1 x In
Long time delay adjustment type - Fixed
Instantaneous pick-up adjustment type Ii - Fixed
Instantaneous pick-up adjustment range - 800 A
Contact position indicator - Yes
mounting support - Backplate
mounting mode - Fixed
Upside connection - Front
downside connection - Front
Connections - terminals Screw connection
Connection pitch - 35 mm
Compatibility code - CVS100
Width - 105 mm
Depth - 86 mm
Height - 161 mm
net weight - 1.5 kg

Environment
Standards - IEC 60947-2 /EN 60947-2
product certifications - GOST IEC
Electrical shock protection class - Class II
Pollution degree - 3 conforming to IEC 60664-1
IP degree of protection - IP40
ambient air temperature for operation -25…70 °C
ambient air temperature for storage -50…85 °C

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 14.000 cm
Package 1 Width - 13.400 cm
Package 1 Length - 19.000 cm
Package 1 Weight - 1.670kg

Unit Type of Package 2 - S04
Number of Units in Package 2 - 12
Package 2 Height - 30.000 cm
Package 2 Width - 40.000 cm
Package 2 Length - 60.000 cm
Package 2 Weight - 20.806 kg
